    Powerful Underfloor Heating Air Source Heat Pump , Industrial Air Source Heat Pump

    Ask Lasest Price
    Brand Name : YouJIA New energy
    Model Number : YW-140D(40P)
    Certification : CCC, ISO, CQC
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10 sets/day
    Delivery Time : 1-2 weeks
    • Product Details
    • Company Profile

    Powerful Underfloor Heating Air Source Heat Pump , Industrial Air Source Heat Pump

    Powerful Underfloor Heating Air Source Heat Pump , Industrial Air Source Heat Pump


    Underfloor Heating Air Source Heat Pump Introduction


    Specially developed for large space, installed and maintained like household air conditioners, unmanned management, no floor space; open working condition design, double wing blow structure, various installation methods, elliptical tube heat transfer technology, spherical seal air supply, Post supply and other functions
    Scope of application
    Factory, warehouse, station, drug store, etc.


    Underfloor Heating Air Source Heat Pump Characteristics


    1. Diverse structure: Two-wing pair blowing structure, realizes ultra-thin pocket design of the unit, breaking the institutional characteristics of traditional air-conditioning;
    2, air curtain anti-condensation spherical air outlet (patent): effectively solve the industrial problem of spherical tuyere condensation, the air supply distance can reach 25 meters;
    3, elliptical tube heat transfer technology (patent): reduce coil resistance, improve heat transfer coefficient, to achieve stable and efficient operation throughout the process;

    DC frequency conversion multi-unit factory professional area air conditioning system solution
    DC frequency conversion technology, IPLV up to 7.55, an average of 6.92; multi-jet tuyere, air supply distance up to 25 meters
    Wall mounted. Various structural forms of the ceiling, easy to deal with various places; multi-connection control technology, easy installation, low investment, quick effect
    Ultra-thin one-to-one, one-to-two low-noise regional jet air conditioning system solution
    Ultra-thin body, no need to reserve the return air space, the fan can be pulled out of the machine, the wind supply distance is far, widely used in factories, supermarkets, canteens, entertainment and other places
    Frequency conversion type direct evaporation factory-specific regional air conditioning system solution
    Well-known components of international brands, reliable performance and high efficiency
    Double system design, energy saving; wide air supply distance, wide distribution of wind; wall and wall cabinets, various installation forms, easy to deal with different places
    Hot and cold water plant-specific regional air conditioning system solution
    Elliptical tube high-efficiency hot and cold heat exchange coil, the air supply distance is up to 25 meters, wall mount, ceiling and two installation methods
    Suitable for large and long pipe systems


    Underfloor Heating Air Source Heat Pump parameters:


    Unit TypeYW-35D(10P)YW-70D(20P)YW-140D(40P)

    Rated power/frequency


    380V 3N~/50HZ

    Cooling mode


    Cooling mode(KW)35.470.8141.6
    input power(KW)11.1622.3246.4
    Heating mode

    Nominal condition

    (7℃)

    Heating(KW)28.857.6115.2
    Rated input power(KW)10.821.643.2

    Low temperature condition

    (-12℃)

    Rated heating capacity

    (KW)

    23.847.695.2

    Rated input power

    (KW)

    9.819.639.2
    Maximum input current(A)27.755.4110.8
    Circulating pump flow (m³/h)6.4312.8725.72
    Refrigerant/charge(R22/Kg)91836
    Hot water rated temperature45℃

    Refrigeration inlet and outlet water temperature
    5~15℃
    Hot water maximum temperature55℃
    waterproof levelIP×4
    Anti-shock protection categoryI Grade
    Ambient temperature range30~40℃
    Unit noise db(A)≤60≤65≤65
    Unit weight(Kg)3206501300
    Unit size(mm)1590*850*16002000*1100*20902200*2000*2170
